65 inch interactive whiteboard with 6 points infrared touch function

Graphic
Detail

65 inch interactive whiteboard with 6 points infrared touch function

Brand： SMT
Serial Number： SMT-IWB6501
Country of Origin： Guangdong, China
Certificate： CE,CB,RoHS,ISO9001

Parameters

Brand： SMT
Serial Number： SMT-IWB6501
Country of Origin： Guangdong, China
Certificate： CE,CB,RoHS,ISO9001

Product Detail

PAYMENT & SHIPPING TERMS

Price Quote	$950-$1900
Minimum Order	1 Piece
Average Delivery Time	10-25 days
Payment Method	T/T
Package Details	1 piece/box
Ability to Supply	3000 pieces per month

PRODUCT DETAILS

65 inch interactive whiteboard with 6 points infrared touch function

Quick Details for 65 inch touch digital signage/65 inch touch LCD display/65 inch touch advertiser/65 inch touch monitor

Type: Whiteboard, Whiteboard, Finger, Pen

Whiteboard Type: Electronic Whiteboard

Brand Name: SMT

Model Number: SMT-IWB6501

Place of Origin: Guangdong, China (Mainland)

Lifetime: 50000HRS

MAX Power Consumption: 270W

Video Format: NTSC

COM Port: USB 2.0

Item Name: Touchscreen Interactive Whiteboard

OEM: yes

Warranty: 1 Year

Backlight type: LED Backlight

Certificates: CE ROHS FCC CCC,ISO9001

Package Type: Quality carton with full wood box packing

General Operation and Uses of SMT Interactive Whiteboard

♦ An SMT interactive whiteboard (IWB) device can either be a standalone computer or a large, functioning touchpad for computers to use.

♦ A device driver is installed on the attached computer so that the interactive whiteboard can act as a Human Input Device (HID), like a mouse. The computer's video output is connected to a digital projector so that images may be projected on the interactive whiteboard surface.

♦ The user then calibrates the whiteboard image by matching the position of the projected image in reference to the whiteboard using a pointer as necessary. After this, the pointer or other devices may be used to activate programs, buttons, and menus from the whiteboard itself, just as one would ordinarily do with a mouse. If text input is required, the user can invoke an on-screen keyboard, utilize handwriting recognition. This makes it unnecessary to go to the computer keyboard to enter text.

♦ Thus, an IWB emulates both a mouse and a keyboard. The user can conduct a presentation or a class almost exclusively from the whiteboard.

♦ In addition, the Interactive Whiteboard is supplied with software that provides tools and features specifically designed to maximize interaction opportunities. These generally include the ability to create virtual versions of paper flipcharts, pen and highlighter options, and possibly even virtual rulers, protractors, and compasses—instruments that would be used in traditional classroom teaching. Interactive whiteboards promote collaboration among students and group discussion and participation. They can be an effective tool for brainstorming due to the fact that notes can be taken on the board and saved to be shared and distributed to students later.

Uses for SMT interactive whiteboards may include:

♦ Running software that is loaded onto the connected PC, such as a web browser or other software used in the classroom.

♦ Capturing and saving notes written on a whiteboard to the connected PC

♦ Capturing notes written on a graphics tablet connected to the whiteboard

♦ Controlling the PC from the whiteboard using click and drag, markup which annotates a program or presentation

♦ Using OCR software to translate cursive writing on a graphics tablet into text

♦ Using an Audience Response System so that presenters can poll a classroom audience or conduct quizzes, capturing feedback onto the whiteboard

Features of SMT 65 inch Interactive Whiteboard

♦ Multi-point touch support

♦ Comes with multi-function software

♦ Comes with WIFI(optional)

♦ Equipped with multiple signal interfaces

♦ Aluminum alloy body with front access touch frame module

♦ Intelligent black board detecting features(Once black board activated, LED-backlit off)

♦ Available in a wide range of sizes: 55”, 65”, 70”,84”, 98” and 100”

Product Name	65" interactive whiteboard
Model	SMT-IWB6501
Viewable size	1428.48mm(W) x 803.52mm (H)
life span	50000 hours
Aspect ratio	16:09
Brightness	400nits
Contrast	4000:01:00
Backlight	LED
View angle	178°(V)/178°(H)
Physical resolution	4096(H) X4096(V)
System of video	PAL/SECAM
Parameters- Touchscreen
Touch technology	Multiple infrared scanning technologies
Touch type	6 points infrared
Touchscreen embedding methods	Front access (Available for front maintenance)
drive mothed	HID free drive
The material of writing surface	4MM tempered glass(anti-glare is optional)
Touchscreen induction mothed	finger, writing pen, gloved hand or any other Non-transparent touch-sensitive media
Touch screen positioning resolution	4096X4096
Parameters - PC (OPS)
Mainboard	H81
OPS CPU	CPU: Intel Core i5
Memory	RAM 8G DDR3
Hard disk	1TB HDD
Operation system	Windows
Graphics card	Integrated
Realtek	Integrated
Wireless keyboard / Mouse	Optional
WIFI	Open end 2.4G/5G,150/300Mbps
Bluetooth	Open end
interface	USB x4, earphone output x1,MIC x1,VGA output x1,Support HDMI Input x1
Parameters - Android
Basic frequency	CPU 4-core 1.2G
System version	android 4.4.2
Memory	DDR3 1G
WIFI	IEEE 802.11 b/g/n 2.4GHz 1T1R
Flash	4G

All pictures and function introduction for 65 inch interactive whiteboard here are only for reference. Accurate details referred to Instruction brochure and Physical Package. SMT has the rights for the final explanation.
